30cm Light Curtain Sensor For Industrial Doors

Ask Lasest Price
Certification :	CE
Brand Name :	JUTAI
Model Number :	PB3-4L15
Price :	Negotiation
Payment Terms :	T/T, L/C, D/A, D/P, Western Union, Paypal, , MoneyGram, Alipay
Supply Ability :	1000 pieces per month
Delivery Time :	5-8 working days

Add to Cart

Product Details
Company Profile

30cm Light Curtain Sensor For Industrial Doors

30cm Light Curtain Sensor Customized for Industrial Doors

Description: Our Infrared Fence Integrated High-Efficiency Alarm System provides independent alarm triggering without the need for an alarm host. It ensures reliable detection with stable infrared beams and offers long-term durability with sealed waterproof and dustproof design.

Key Features:

Stable Infrared Beam: Utilizes high-quality imported industrial-grade infrared emitters for stable beams and extended service life.
Sealed Waterproof and Dustproof: Resistant to wind and rain, ensuring reliable outdoor performance.
Accurate Detection with Anti-False Alarm: Prevents false alarms caused by small animals or debris. Signals are triggered only after a single beam blockage for 2 seconds or immediate triggering if two or more adjacent beams are blocked (adjustable by users).
180° Full Directional Rotation: Equipped with a 180° omni-directional rotation focus for easy and flexible installation.
Anti-Dismantling Function: Triggers an alarm if the infrared grating is tampered with or if the cable is cut.

Applications:

Alarm: Ideal for fences, balconies, patios, backyard or pool entries, private entryways, or corridors.
Gate Safety: Suitable for automatic gates, barriers, sliding doors, and other safety applications.

Height	30cm/100cm/200cm
Beam Group	4/8/16/32
OEM	YES

Specification	Value
Number of Beams	4/8 (or customizable options)
Height	30cm, 100cm, 200cm (or customizable options)
Detection Distance	15 meters
Working Voltage	DC 12-24V
Transmitter Operating Current	<50mA
Receiver Operating Current	<50mA
Response Time	50/100/150/200ms (adjustable)
Trigger Time	Block a beam of light, trigger in 2 seconds; block adjacent 2 beams or more, trigger immediately
Induction Method	Single beam trigger or Multi-beam trigger (selectable)
Working Temperature	-20°C to 60°C
Ambient Temperature	Up to 90% RH (no condensation)
Alarm Output	Wired Output, Relay Output 30 VDC @ 2A, 125VAC @ 1A
Output Way (Wired Model)	Wired transmission (NO/NC)
Rotation Angle	180 degrees horizontal
IP Level	IP65
Material	Aluminum Alloy and PC Plastic

30cm Curtain Photocell Waterproof Photoelectric Sensor for Most Commercial and Industrial Door
